Embidio System

All-in-One Voice Assistant Development Platform

embidio system

Feature Highlights

  • Ready-to-use stand-alone voice development system.

  • Core based on Embidio Hub (XMOS) and Raspberry Pi.

  • Integrated 8-microphone array for 360° capture.

  • Integrated stereo speakers (2x 4W).

  • Optional 10-inch touch display.

  • Integrated LED lighting for visual feedback.

  • Easy connection to cloud platforms (e.g., Conhive).

  • Cost-effective solution streamlining development.

Rapid Development

Preconfigured system allows immediate start for pilot projects and voice assistant development.

All-In-One Solution

Combines mics, speakers, processing (Embidio Hub + RPi), and optional display in one unit.

Interactive Interface

Optional large touch display and LED lighting enhance control, feedback, and user interaction.

Cloud Ready

Designed for easy connection to platforms like Conhive and customization (e.g., wake word).

Development Use Cases

  • Smart Office Assistant Prototypes

  • Intelligent Voice Assistant Platforms

  • Digital Companion / Accessibility Aid Development

  • Meeting Room Assistant / Transcription Systems

  • Information Kiosk Voice Interfaces

  • Voice Control System Evaluation

embidio system

Technical Specifications

Highlights

  • Core Processing
    Embidio Hub (XMOS) + Raspberry Pi Compute Module (or similar)
  • Microphone Array
    Integrated 8 digital MEMS
  • Speaker
    Integrated 2 x 4 W Stereo
  • Display (Optional)
    10-inch Touchscreen
  • Connectivity
    Ethernet, Wi-Fi/Bluetooth (via RPi), USB
  • LEDs
    Integrated controllable LEDs
  • OS
    Linux (on Raspberry Pi)

Audio Processing (via Embidio Hub)

  • Input Channels
    8
  • Output Channels
    2 (Stereo)
  • Sampling Rates
    16 / 48 kHz
  • DSP Features
    Beamforming, Noise Reduction (NR), Acoustic Echo Cancellation (AEC), AGC, EQ, etc. (See Hub page for details)

Signal Processing Details

  • Leverages the full DSP capabilities of the integrated Embidio Hub (See Hub page for details).
